Reed 1H is the latest addition to our entry level tonearm series.

Differences between acoustical properties of damped and undamped carbon fiber wand are shown in Figures 1 and 2.

And, for the first time, we introduce carbon fiber as primary Reed 1H’s armwand material.

After a thorough research we found a way to make the carbon fiber armwand’s acoustic properties close to ones that normally are typical for the wood.

By using soft wood to damp the carbon fiber tube, our new armwand’s acoustic properties become considerably better than using carbon fiber alone, and can be compared to wooden armwands.

SPECIFICATIONS

Effective length                                            9.5″                10.5″               12″

Mounting distance, mm                             223                 251.6              295.6

Pivot to spindle distance, mm                   223                 251.6              295.6

Overhang, mm                                             17                   15.4                 13.4

Offset angle, deg                                         22.9                20.7                 17.6

• Worldwide shipment service where the Distributor or Dealer does not exist
• Free ship cost in Europe for order over 500€ (except speakers, we offer  50% of ship cost)
• Free ship cost Worldwide  for order over  2000€ (except speakers, we offer  50% of ship cost )

Buy Now

Reed 5A tonearm introduced as angling- 90o -tangential-pivot-tonearm, it is based on Double Birch/Thales geometry and will complement our tangential tonearm lineup.

Below is the scheme of Double Birch/Thales geometry ( Fig.1).

Tonearm geometry is optimized for minimal tracking error.

Operating principle of the tonearm is illustrated in

https://www.youtube.com/watch?v=oIoHvCE9F0I

P1, O1, P3 – Thales’ semicircle,

P1-A1-P3, P1-A2-P3, P1-A3-P3 angles are 90⁰ each,

A1,1B1 = A2,1B2= A3,1B3 segments represent tonearm length,

1B – vertical axis of the tonearm,

1P2 – center of the circle,which is drawn through three points -1B1,1B2,1B3,- axis of rotation of the back link component

2P2 – center of the circle,which is drawn through three points -2B1,2B2,2B3,- axis of rotation of the front link component

1B1,2B1 = 1B2,2B2 = 1B3,2B3 – tonearm lever.

Armtube suspension system is similar to the one used in Reed 3P tonearm.

Tonearm’s back link uses low-noise ceramic rolling bearings.

Lever uses low-noise ceramic rolling bearing and rests on the sapphire – molybdenum carbide thrust bearing.

Sapphire – molybdenum carbide thrust bearings are also used for tonearm’s front link, vertical and horizontal axes.

Tonearm has VTA and azimuth setup and can be configured with Reed or SME (universal headshell connector) headshells.

To make sure tonearm setup is precisely horizontal, tonearm has integrated level and horizontal plane adjuster.

Comparing to regular pivot tonearms, Reed 5A does not require antiskating and has much less absolute tracking error (max. tracking error is +/- 4 Minute of Angle (MOA) (Fig.2).

Pivot tonearms – approx. 1.2 – 2.5 deg. (Fig.3).

Comparing to other tangential tonearms, Reed 5A does not require any additional devices to work (e.g. compressors, electronic controllers), is compact and can be easily mounted on a wide range of turntables.

SAMPLES OF FINISH Pictures below are for illustration of finishing only; tonearm model may be different from described above.

Silver -Black

Wood SAMPLES

1.Cocobolo - 2. Macassar Ebony - 3. Wenge - 5 Teak Light - 6 Teak dark
